Medical Horizontal Autoclave Steam Sterilizer Class N with Pulse Vacuum Function Electrical Door Fully Automatic, CA-STH-ND Series
- Horizontal type, Jacket structure
- Chamber volume: 150L，200L, 300L, 400L
- Working temperature: 105-138℃
- Working pressure: 0.245 Mpa
- Can set multiple sterilization programs
- Multiple safety protection
Description
- Horizontal circular inner chamber and jacket structure, safety, heat preservation, and drying function；
- Disc type embedded gear and Electric lock door structure, safe and reliable;
- Door seals are pneumatic
- Equipped with a standard equipment verification interface
- Pipeline system for the optimal design, SUS 304 pipeline, clamp structure, quick assembly
- Control system: HMI man-machine interface, touch screen + microcomputer;
- F0 value and temperature time double guarantee sterilization effect, with perfect sterilization records;
- With program selection, parameter setting, equipment operation, report processing and traceability functions;
- Multiple safety protection(over-temperature, over-pressure protect)
- Built-in printer
- USB function
Specifications
| Model | STH-N150D | STH-N200D | STH-N300D | STH-N400D |
| Volume（L） | 150 | 200 | 300 | 400 |
| Overall Dimensions (L*W*H)mm |
1260*690*1700 | 1490*690*1700 | 1400*850*1730 | 1680*850*1730 |
| Chamber Size(Ø*L)mm | φ472*850 | φ472*1080 | φ620*960 | φ620*1230 |
| Steam Consumption (kg) | ≤12 | ≤13 | ≤18 | ≤22 |
| Water Consumption(kg) | ≤30 | ≤30 | ≤40 | ≤40 |
| Power(kW) | ≤2+⑮ | ≤2+⑮ | ≤2+⑱ | ≤2+⑱ |
| N.W. / G.W. (kg) | 400/500 | 450/550 | 510/610 | 650/750 |
| Shipping Dimension (W*D*H) (mm) | 1570*840*1850 | 1740*840*1850 | 1580*970*1960 | 1870*980*2000 |
Main Technical Parameter
| Design Pressure | -0.1~0.25MPa |
| Design Temperature | 139℃ |
| Working Pressure | 0.225MPa |
| Working Temperature | 105~136℃ |
| Temperature Equilibrium | <+2.0℃ |
| Vacuum | -0.086MPa |
| Water Pressure | 0.1-0.2MPa |
| Compressed Air Pressure | 0.4~0.7MPa |
| Steam Pressure | 0.3~0.7MPa |
| Power Voltage | Three-phase five-wire AC380V/50Hz |
Note: The machine needs external compressed air for door sealing and the air consumption is not large. If the end users don’t have a ready air source, they can choose to use an air compressor of about 40L.
