Gradient PCR Machine, CA-PCRTC-GP
- Gradient type
- Sample Capacity: 96 well plate, 96X0.2mL PCR tube
- Max. Heating/Cooling rate: 5℃/Sec
- Temperature uniformity: ±0.2℃ @35-72℃
- 7 inch Large color touch panel screen
- High performance DSP and temperature control
- Large user program storage
Description
- Reliable heating/cooling elements and precise temperature control
- Unique design of block ensures the temperature uniformity and repeatable results
- 7 inch Large color touch panel screen for easy programming with user friendly software
- High performance DSP and temperature control
- Fast heating and cooling rate
- Large user program storage
- Built-in WIFI module, connecting via LAN with a PC host computer, simultaneous control of multiple PCR instruments with one computer
- USB interface, support for saving/retrieving PCR data on U disk, support for updating software on U disk and LAN, customisable programs, file customization, multi-file storage.
- 7 inch Large color touch panel screen
- It is for easy programming with user friendly software
- Long lasting peltier, precise temperature control by zone
- Compatible with common tubes of different heights
- Eight rows of tubes and 96-well plates
SPECIFICATIONS
| Specifications | PCRTC-GP |
| Sample Capacity | 96×0.2mL PCR tube | 12×0.2mL PCR-8 strips | 0.2mL 96 PCR Microplate |
| Heating Temperature Range | 0-105℃ |
| Lid Temperature Range | 30-115℃ |
| Temperature Display Accuracy | ±0.1℃ |
| Temperature Control Accuracy | ±0.1℃ |
| Temperature uniformity | ±0.2℃ @35-72℃ |
| Max. Heating/Cooling Rate | 5℃/Sec |
| Gradient Temperature Setting Range | 30-105℃ |
| Gradient Range | 1-42℃，Turn off gradient on input 0 |
| Adapter block material | Aluminum |
| Display | 7″ LCD 1024×600 |
| Input | Touch panel |
| User defined file system | Max. 30 steps in a single program, 99 cycles |
| Power off protection | Yes |
| Power Supply | 100~120V/200~240V，50/60Hz 600W |
| Dimension [D×W×H] ( without the heating block ) | 280x370x250mm |
| Weight | 9.5kg |
