Description
Measurement Parameters
Turbidity, total suspended solids (TSS)
Features
•2 to 7 points calibration using the Formazin Standards
•Selectable 4 turbidity units, including the NTU, FNU, EBC, and ASB, C, etc.
•Reset function automatically resumes all settings back to the factory defaults
•Expanded memory stores or recalls up to 200 data sets
•TSS conversion factor ensures the accurate measurement of the total suspended solids
•Auto-Read function senses and locks a stable reading
•Setup menu allows setting the date and time, measurement mode, resolution,
•Password protection prevents unauthorized calibration and settings
•USB communication interface makes it easy to transfer data to a PC
Applications:
• Industrial wastewater plants
• Municipal water and other industrial applications
Ordering Information
BEP-TB200: Meter, turbidity standards (0.02, 200, 500, 1000 NTU), sample vials, lint-free cloth, and power adapter
SPECIFICATIONS
| Model | CA-BEP-TB200 |
| Turbidity | |
| Range | 0 to 2000 NTU, 0 to 500 EBC, 0 to 9999 ASBC |
| Resolution | 0.01 (0 to 99 NTU), 0.1 (100 to 999 NTU), 1 (1000 to 2000 NTU) |
| Accuracy | ±2% of reading (0~500 NTU), ±3% of reading (501~2000 NTU) |
| Calibration Points | 2 to 7 points |
| Calibration Standards | 0.02, 10, 200, 500, 1000, 1500, 2000 NTU |
| TSS | |
| Range | Depending on the TSS conversion factor |
| Resolution | 0.1, 1 |
| Accuracy | ±3% of reading |
| General Specifications | |
| Light Source | Infrared-emitting diode (850nm wavelength) |
| Detector | Silicon photodiode |
| Stray Light | <0.02 NTU |
| Sample Volume | 30ml |
| Memory | Stores up to 200 data sets |
| Output | USB communication interface |
| Display | 4.5″ TFT LCD |
| Power | DC12V, using AC adapter, 220V/50Hz |
| Dimensions | 250(L)×177(W)×96(H)mm |
| Weight | 1.2kg |
